RABio w8
RABio w8 Biopotentials Acquisition System
​
RABio w8 is a low-cost, low-power, portable and wireless device for the acquisition of electrophysiological signals (e.g., EEG, EMG, ECG, EOG). RABio w8 provides simultaneous acquisition from 8 channels (request for availability of 16-channel and 32-channel version) at up to 500 Hz with 24-bit precision. The lightweight design and robust acquisition makes it suitable for both in-lab and outdoor environments. RABio w8 is a low-cost acquisition system within reach for any research group. Single or double-colored cases available: red, blue, yellow, black and white.
Choose yours!
​
Special
launch offer
GUI license = 390 EUR
RABio = 999 EUR
Total = 1389 EUR
New Release! RABio w8 Mini
Similar specs, reduced weight and size
​
Click to enlarge
Click to enlarge
PRODUCT
SPECS
Wearable
Dimensions 93 x 54 x 39 mm
Wireless
Bluetooth communication
24+ hours battery life
Rechargeable Li-Ion battery via USB-C.
24-bit ADC
With up to 500 Hz sampling rate.
Synchronization
Precise wireless trigger and wired external trigger port.
Electrical
1 GOhm input impedance, 115 dB CMRR.
Software included
Data acquisition API and graphical user interface.
Matlab
Fully compliant with Matlab.
8 channels + REF + DRL
Configurable gain (individual) and sampling rate.
EEG | EMG | ECG
Suitable for multiple biopotentials.
Robustness
Suitable for out-lab research.
Demos included
​
CONTACT
Plat-EEG project and Nicolo Association.
RABio w8 was developed within the Plat-EEG project (Junta of Andalucia, Spain), born in the BCI Lab of the University of Granada. Several engineers and neuroscientists work on that project in order to develop EEG-based systems with the latest advances in technology. Nicolo Association was born to support research and development of neurotechnologies and rehabilitation for disabled people. Nicolo is a nonprofit organization and the Plat-EEG profits are used for those activities.
Email:info@nicolo.es
